Install and Connect SCC1 (Single-Carrier Cabinets)
Task List: Install and Connect Single-Carrier Cabinets (SCC1)
SI Installation and Upgrades 369
June 2004
Figure 109: Front Mounting Angle Location
Return to Task List
Figure notes
1 #12-24x1/2-inch Thread Forming
Screw
2 Control Cabinet
3 Front Mounting Angle
4 Hex Head Bolt
5 Nylon Insulating Washer
6 Concrete Floor
7 Concrete Floor Anchor
4
1
3
2
5
6
7
r781854a CJL 030896
