Add IP Solutions
Task List: Upgrade TN802B to TN2302AP
SI Installation and Upgrades 615
June 2004
Replace the Cables
Return to Task List
1 Disconnect the network cable from the Ethernet connection.
2 Turn off the modem and unplug it from the AC outlet. It is not needed for the TN2302AP.
3 Disconnect the modem’s RS232 port from the H600-512 external cable assembly.
From the rear of the cabinet:
4 Disconnect the amphenol connector on the external cable assembly from the backplane connector
corresponding to the TN802B circuit pack.
5 Connect the amphenol connector on the TN2302AP Amphenol adapter to the backplane
connector corresponding to slot selected for the TN2302AP circuit pack.
NOTE:
The TN802 circuit pack occupied 3 slots, and the cable was connected to the rightmost
slot. For convenience use the same rightmost slot vacated by the TN802 circuit pack for
the TN2302AP circuit pack. The other 2 slots are now available for other circuit packs.
6 Connect the network cable to the Ethernet connector on the TN2302AP Amphenol adapter.
Return to Task List
Install the Circuit Packs
Return to Task List
1 If replacing the TN799 circuit pack, install the TN799DP circuit pack in the slot vacated by the
TN799 circuit pack.
2 For convenience install the TN2302AP circuit pack in the rightmost slot vacated by the TN802
circuit pack. The other 2 slots are now available for other circuit packs.
When you plug in the TN2302AP IP Media Processor, the circuit pack starts to boot. The RED LED stays
on until an IP address is assigned to the circuit pack.
3 Type list configuration all and press Enter to verify that the system recognizes the TN2302AP
circuit packs.
Return to Task List
Perform Additional Administration Steps
Return to Task List
1 Administer the TN799DP C-LAN, if necessary. Refer to the Administration for Network
Connectivity for Avaya™ Communication Manager (555-233-504).
2 Administer the IP Media Processor, which is usually done remotely. Call your service
representative to start the process.
3 Complete the administration and testing. Refer to Perform Initial Administration Steps for C-
LAN and IP Media Processor on page 607 and Test the External Connection to the LAN on page
610.
