Task list: Install the TN802B in IP Trunk mode
642 SI Installation and Upgrades
June 2004
2 Click the Protocols tab, and examine the Network Protocols. TCP/IP protocol should be
the only one listed.
3 Click OK.
Return to Task List
Test the External Connection to the LAN
Return to Task List
To test the external IP connections, ping the IP Interface server and ping a known computer connected to
your network.
1 Click Start > Programs > Command Prompt.
2 Type ping nnn.nnn.nnn.nnn (which is your IP address).
— If everything is configured correctly, the system responds with the following message:
Reply from nnn.nnn.nnn.nnn: bytes=32 time<##ms TTL=###
— If no response, verify the IP-address information and check the connectivity, including the
cabling.
3 At the command prompt, type ping nnn.nnn.nnn.nnn (which is the IP address of your gateway).
— If everything is configured correctly, the system responds with the following message:
Reply from nnn.nnn.nnn.nnn: bytes=32 time<##ms TTL=###
— If no response, verify the IP address information and check the connectivity, including the
cabling.
— If all else fails, click on Start > Settings > Control Panel > Network. Select the Adapters
tab and highlight the
[2] DEC adapter.
—Click Properties > Change.
—From the
Duplex Mode drop down menu, select a setting that matches the switch/hub
that the TN802B connects to. For example, 10BaseT Full Duplex or 10BaseT No Link
Test.
4 At the command prompt, type ping nnn.nnn.nnn.nnn (which is the IP address of another
external computer beyond the gateway).
— If you have connectivity, the system responds with the following message:
Reply from nnn.nnn.nnn.nnn: bytes=32 time<##ms TTL=###
— If no response, verify the IP address information and check the connectivity, including the
cabling. Consult your IP network administrator.
5 Type exit and press Enter.
Return to Task List
Test the IP Interface Onboard LAN Connections
Return to Task List
To test the onboard LAN connections, ping the IP Interface server and the processor on the TN802B IP
Interface.
1 Click Start > Programs > Command Prompt.
To Next Page
