23. Illumination Engine front
23. ILLU M INATION ENGINE FRONT
The illumination Engine front contains the Relay Tube Assy (Lens), Motorized Iris Assy, Folding Mirror assembly and CLO sensor
(Constant Light Output).
GP6 Iris assy and Relay Tube assy can be removed without removing illumination engine.
Adjustable mirror an d CLO can only be accessed after removing t he complete engine core, including lens shift.
23.1 Iris assembly
Location of the Iris assembly
Image 23-1
Location of the iris assembly
Image 23-2
Complete Iris assem bly
723–0016 F90 01/12/2017 119
