16. Power Supply Unit (PSU)
16. POWER SUPPLY UNIT (PSU)
16.1 A C Input
There are two versions of the po wer su pply. The first f ew units of the p rojector is equipped with 504-0613-00.
This powersu pply is cer tified for 240V only, an d will reduce output (laser) power when used w ith 110V.
There is no rating label o n the PSU. T he ratings are described on the projector label.
Part Number PSU
Rating
504-0613-xx
110-240V, 50-60Hz , 12A (For projector label only. No rating on
PSU label)
R7681400
110-240V, 50-60Hz , 16-12A (For projector label only. N o rating
on PS U label)
16.2 Output specification
The output connectors contain output voltages from 5 different internal converters.
Below is the specifie d output voltage a nd output current capacity of each c onverter.
Output Name
Voltage Level
Capacity Connector used
11,5V_STB 11,55V +/- 2,6%
(11,25 — 11,85V)
0,4A Mainboard
12V-1 12,36V +/- 3,45%
(11,94 — 12,8V)
10A Mainboard
12V-2
12,36V +/- 3,45%
11,91 — 12,8V)
8,64A Thermal Hub
24V 24V +/- 1V 10A Thermal Hub
Laser driver supply 380V +/- 3,42%
(367 — 393V)
4,13A Laser Driver
723–0016 F90 01/12/2017 59
