24. Lens shift assembly
Image 24-8
Image 24-9
3. With the lens shift assembly rem oved, the GP6 /7 Dumpl. XPS Actuator assy is loos e and can be removed.
Note: See "XPS actuator", page 53 for details tuning ne w actuator if it has been replaced.
Image 24-10
24.7 TIR Prism
Use cotton gloves or nger nuts when ever handling the TIR prism
24.7.1 Remove the TIR prism
1. Remove 4 screws (TX8 M2,5x6)
2. Carefully pull out the Prism Clip Prism us ing a at scre w d river.
723–0016 F90 01/12/2017
127
