6. GP6 periodical maintenance
6. GP6 PERIODICAL MAINTENA NCE
About
There are some components that have limited lifecycle and need to be replaced within specified intervals. By following those inter-
vals, the projector will maintain the original performance. Otherwise, the performance of the projector gradually will decrease. T he
service components and their intervals are specified in the table below.
The GP6 Low F requency Maintenance (LFM) schedule has 2 main service intervals: 20.00 0 hours and 40.000 ho urs.
Complete service kits are available for purchase, see chapter “Service Kits Available”.
The components listed in the 20.000 hour interval must be also exchanged during the 40.000 hour interval
service.
Both intervals must be performed by au thorized service technicians in controlled environments, typically in
a service center.
6.1 Service Interval Matrix
Refer to chapter "Sc heduled operations", page 87 for detailed procedures describing replacement of service components.
The table below shows comp onent which must be replaced at each service interval, the qua ntity ne eded, and the article number.
The item descriptions does not necessarily reflect the description in the parts list.
Service Interval Matrix
20.000 h our interval.
(20.000, 40.000, 60.000.....hours)
40.000 hour Interval
(40.000, 80.000, 120.000,... hours)
Component
Pcs Article No
Component
Pcs Article No
Phosphor wheel fans
2 504-0544-xx Fan laser driver 1 504–0623–xx
Fan PSU
1 535–0005–xx
Main system fans
5 504–0623–xx
Fan PCB
1 504–0624–xx Liquid cooling,
radiators
4 504–0372–xx
Fan optics 1 504–0625–x x Liquid cooling, DM D 1 504–0372–xx
GP6 / GP7 Phosphor
wheel
2 R9801433
GP6 / GP7 Color wh eel
cassette, Brightness
1 R9801431
GP6 / GP7 Color wh eel
cassette, Color
1 R9801432
GP6 / GP7 Laser cluster
blue
2 R9801430
GP6 / GP7 Dumplight
XPS actuator assembly
1 R8781693
6.2 Service Kits available.
In or der to simplify the ordering of service c ompone nts, complete service kits are available from the Barco se rvice center, see table
below for more details.
Available comp lete service kits
20 000 hours 40 000 hou rs
Component Consisting of
Kit
needed
pr
ser-
vice
[pcs]
Kit art. no.
Component Consisting of
Kit
needed
pr
ser-
vice
[pcs]
Kit art. no.
723–0016 F90 01/12/2017 27
