12. Phosphor wheel
12. P HOSPHOR WHEEL
Overview
• Replace the phosphor wheel assy
• Entering Prospector diagnos tic tool
• Calibrating the phosphor wheel
12.1 Replace the phosphor wheel assy
See chapter "Phosphor wheels (2 pcs)", page 87
12.2 Entering Prospector diagnostic tool
Prospector Tool
To access the web interface, use a web browser and enter http//xxxxxx:9999, where x xxxxx is the IP a ddress for the p rojector, and
9999 are the code for entering Prospector. As an example: http//192.168.1.100:9999.
The IP Address for the pr ojector is displayed in the OSD Menu: System/Setting/Communication/LAN.
The following s creen will appear; yo u are now working in P rospector.
Image 12-1
12.3 Calibrating the phosphor wheel
The c alibration of t
he Phosphor wheels is performed via the Prospector application in the projector.
723–0016 F90 01/12/2017
49
