1. Introduction
1. INTRODUCTION
Overview
• Scope and limitations
• Copyright
• Trademarks
• Required Handtools
1.1 Scope and limitations
Scope
This doc ument is intended to describe fault resolution, low frequency maintenance and parts replacem ent procedures for the Barco
F90. Only partners named in service agreement with Ba rco Fredrikstad AS may carry out procedures detailed in this document. In-
formation contained herein is subject to change without further notice; please refer to online docum entation for updated information.
1.2 Copyright
Copyright
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transm itted
or stored in a retrieval system without prior written consent of B arc
o.
1.3 Trademarks
Trademarks
Brands and product names mentioned in this manual may be tradem arks, registered trademarks or copyrights of their respective
holders. All brands and product names mentioned in this manual serve as comm ents or e xamples and ar e not to be understood as
advertising for the product or their manufacturers.
1.4 Required H andtools
Required Handtools
The following tools are needed for servicing the unit:
• Screwdriver,s, Torx6, 8, 10, 20.
• Allen K ey, Size 1.5, 2, 3, 5m m
• Scalpel
• Screwdriver, Flat head 4m m
• Ionized pressurized air for cleaning optical components
• Adjustable thermal heater for releasing Cooling s ystem.
• Suitable cleaner for therm al transfer c ompoun d, (Brake / clutch cleaner). Isopropanol can be used, but are not as powerful as
brake c leaner.
Unless otherwise indicated in the procedure, screw torque to be applied is 0.3 Nm .
723–0016 F90 01/12/2017
