Barco F90 User Manual

5. GP6 system functional description
5.4 Wiring Matrix
Partnumber Descripon Overall Length Quanty PCB Name Conn. No. PCB Name Conn. No.
534-0001-05 Switch Thermal Le / Right 570 2 PCB Main Board J8 Switch Thermal Le / Right
PCB Main Board J35 Switch Thermal Le / Right
534-0002-02 Switch Thermal DMD 355 1 PCB Main Board J12 Switch Thermal DMD
534-0003-04 #N/A 530 1 PCB Main Board J17 CW Board J1
534-0005-02 CLO 190 1 Thermal Hub Board J30 CLO Board J1
534-0006-04 Comm PSU + USB 440 2 PCB Main Board J16 Main PSU J5
Thermal Hub Board J10
Front USB and Trigger Board
J1
534-0007-02 Comm Hub Link 1/2 255 2 PCB Main Board J1 Thermal Hub Board J11
PCB Main Board J38 Thermal Hub Board J12
534-0008-03 Comm LD 280 2 PCB Main Board J4 Laser Driver board J2
PCB Main Board J63 Laser Driver board J2
534-0009-00 Switch Airfilter 170 1 Thermal Hub Board J13 Switch Airfilter
534-0011-01 Wobbulator 420 Thermal Hub Board J33 Wobbulator
534-0012-03 Branch Inlet Fans 565 1
Thermal Hub Board J24
Branch Inlet Fans
534-0012-03 Branch Inlet Fans 565 1
Thermal Hub Board J34
Branch Inlet Fans
534-0013-03 IR Front 240 1 Thermal Hub Board J17 IR Board J1
534-0014-00 Laser Driver Output 1 240 6 Laser Driver board J1 PCB Laser Blue J1
Laser Driver board J3 PCB Laser Blue J1
Laser Driver board J10 PCB Laser Blue J1
Laser Driver board J11 PCB Laser Blue J1
Laser Driver board J12 PCB Laser Blue J1
Laser Driver board J13 PCB Laser Blue J1
534-0015-01 Laser Driver Output 2 100 6 Laser Driver board J1 PCB Laser Blue J1
Laser Driver board J3 PCB Laser Blue J1
Laser Driver board J10 PCB Laser Blue J1
Laser Driver board J11 PCB Laser Blue J1
Laser Driver board J12 PCB Laser Blue J1
Laser Driver board J13 PCB Laser Blue J1
534-0022-00 No Info No Info 0 Thermal Hub Board J6
534-0023-01 No Info No Info 0 Thermal Hub Board J5
534-0024-03 Lens 200 2 Thermal Hub Board J7 PCB Lens Shi J5
Thermal Hub Board J40 PCB Lens Shi J5
534-0025-02/400-0908-00 Cable Motor Illuminaon Iris 300 1 Thermal Hub Board J4 Motor, Illuminaon Iris
534-0026-01/400-0909-00 Cable Motor Lens Shi 320 1 Thermal Hub Board J1 Motor, Lens shi
534-0027-03 Switch Iris 390 2 Thermal Hub Board J37 Switch, Iris
534-0029-00 NTC Laser Internal 45 12 PCB Laser Blue J2 NTC Laser Internal
534-0031-01 Sensor Opcal H and V 345 2 Thermal Hub Board J18 Sensor Opcal H and V
Thermal Hub Board J19 Sensor Opcal H and V
534-0033-01/502-0405-01 Peler DMD Front 160 1 Thermal Hub Board J27 Peler Element Front
534-0034-02/502-0406-02 Peler DMD Rear 210 1 Thermal Hub Board J28 Peler Element Front
534-0035-02 Peler DewPoint 200 2 Thermal Hub Board j26 Peler DewPoint
Thermal Hub Board J25 Peler DewPoint
534-0036-03 NTC DMD Front and Rear 200 2 Thermal Hub Board J38 NTC DMD Front and Rear
Thermal Hub Board J39 NTC DMD Front and Rear
534-0038-05 Comm PhWheel 570 2 PCB Main Board J53 CW Board J1
PCB Main Board J54 CW Board J1
534-0039-00 1 NA
534-0040-02 Power Hub 460 1 Thermal Hub Board J29 Main PSU J3
534-0041-03 Power Laser 380 1 Laser Driver board P1 Main PSU J2
534-0042-04 Power Main 380 1 PCB Main Board J30 Main PSU J4
534-0043-02 390 Power Keyboard 220 1 PCB Main Board J19 Keypad
534-0044-02 IR Top 145 1 PCB Main Board J7 IR Receiver J1
534-0045-04 Switch Boom 150 2
534-0046-02 Temp Inlet 250 2 PCB Main Board J27 PCB Temp Sense J1
PCB Main Board J28 PCB Temp Sense J1
534-0047-03 #N/A 335 Main PSU PCB Busbuffer Adapter
534-0049-03 Branch Pump Laser 615 1 Thermal Hub Board J35 Branch Pump Laser
504-0624-00 Blower PSU / PCB 258 2 Thermal Hub Board J22 Blower PSU / PCB
Thermal Hub Board J23 Blower PSU / PCB
504-0623-00 Axial Inlet / LD 178 6 Branch Inlet for fan Axial Inlet / LD
Thermal Hub Board J20 Axial Inlet / LD
504-0544-02 Blower Phosphor 185 2 CW Board J3 Blower Phosphor
504-0625-00 Blower Opcs (RER) 335 1 Thermal Hub Board J21 Blower Opcs (RER)
502-0372-00 Liquid Cooler 200 5 Liquid Cooler
529-0013-00 Flex 40p 200 1 PCB Main Board J20 Keypad
Cable Roung
Note: Cables with no Connecon 2, indicates that they ends up in a
complete module assy.
From
To
Cable art. no.,specificaons, quanty
Connecon 2
Connecon 1
Image 5-3
723–0016 F90 01/12/2017 21
