Display Screen
Display Screen
The display screen enables you to view font attributes and other formatting
features directly on the screen while you are entering and editing data.
The screen displays one label, or one area on a multi-area label, at a time. For
labels with multiple areas, use Print Preview (see page 5-2) to view all areas
together.
Status Information
The header bar (top) and status bar (bottom) display permanently on the screen
and contain the following information:
1 Font size with Autosize indicator 7 Editor screen
2 Degree of text rotation in Editor 8 Ribbon remaining
3 Media product and size 9 Battery charge remaining
4 Media type 10 Indicates Caps Lock is on
5 Number of areas on current label 11 Media (labels) remaining
6 Number of labels in current file
