Brother MFC-9330CDW Service Manual

2-84
Confidential
4.2.4 Wrinkles on paper
<User Check>
- Check if the paper is loaded into the each paper tray correctly.
- Turn back the paper loaded in the paper tray or change the orientation of the paper by 180
°.
- Adjust the paper guide corresponding to the paper size.
- Check if the thickness of the paper is 60 to 105 g/m
2
.
(60 to 163 g/m
2
for manual feed slot.)
- Check if paper is not damp.
- Check that no dust adheres to the fuser unit.
- Check whether the paper type is appropriate.
4.2.5 Paper inclines diagonally
<User Check>
- Check if the paper is loaded into the each paper tray correctly.
- Adjust the paper guide corresponding to the paper size.
- Check if the thickness of the paper is 60 to 105 g/m
2
.
(60 to 163 g/m
2
for manual feed slot.)
- Check if too much paper is loaded in the tray.
Step Cause Remedy
1 Fuser unit failure Replace the fuser unit.
Step Cause Remedy
1 Registration clutch failure Replace the registration clutch.
2 Paper feed unit failure Replace the paper feed unit.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
