Brother MFC-9330CDW Service Manual

3-4
Confidential
4. SCREW TORQUE LIST
Note:
For verifying the shape of each screw, refer to “3. SCREW CATALOGUE” in this chapter.
Location of screw Screw type Q' ty
Tightening torque
N
·m (kgf·cm)
Fuser cover L Taptite bind B M3x10 1 0.45±0.05 (4.5±0.5)
Fuser cover R Taptite bind B M3x10 1 0.45±0.05 (4.5±0.5)
Fuser unit
Taptite pan (washer) B M4x12 DA 2 0.7±0.05 (7±0.5)
Registration sensor ASSY Taptite bind S M3x5 1 0.5±0.1 (5±1)
Side cover L Taptite bind B M4x12 2 0.9±0.1 (9±1)
Side cover R Taptite bind B M4x12 2 0.9±0.1 (9±1)
Joint cover side L Taptite bind B M4x12 1 0.7±0.1 (7±1)
Main shield cover plate Taptite cup S M3x8 SR 4 0.7±0.1 (7±1)
Modem FG harness Screw pan (S/P washer) M3.5x6 1 0.5±0.05 (5±0.5)
ADF
FG harness Taptite cup S M3x8 SR 1 0.5±0.05 (5±0.5)
Panel FG harness Taptite cup S M3x8 SR 1 0.5±0.05 (5±0.5)
Document scanner unit Taptite bind B M4x12 1 0.8±0.1 (8±1)
Hinge ASSY L Taptite cup S M3x12 3 0.8±0.1 (8±1)
Hinge R support Taptite cup B M3x10 1 0.5±0.05 (5±0.5)
Hinge arm R Taptite cup B M3x10 3 0.5±0.05 (5±0.5)
ADF unit Taptite cup B M3x10 1 0.5±0.05 (5±0.5)
Upper ADF chute Taptite cup B M3x10 5 0.5±0.05 (5±0.5)
Lower ADF chute Taptite cup B M3x10 3 0.5±0.05 (5±0.5)
ADF FG harness Taptite cup S M3x8 SR 1 0.7±0.1 (7±1)
Drive frame ASSY Taptite cup B M3x10 3 0.5±0.05 (5±0.5)
ADF motor Screw pan (S/P washer) M3x6 1 0.6±0.1 (6±1)
LED FG harness
Taptite pan (washer) B M4x12 DA 1 0.8±0.1 (8±1)
Joint cover open button
holder
Taptite bind B M4x12 5 0.7±0.1 (7±1)
Sub frame ASSY Taptite bind B M4x12 5 0.7±0.1 (7±1)
LED FG harness Taptite cup S M3x8 SR 1 0.4±0.05 (4±0.5)
LED FG harness Taptite cup S M3x8 SR 1 0.5±0.05 (5±0.5)
Modem PCB ASSY Taptite bind B M4x12 2 0.7±0.1 (7±1)
Modem shield cover Screw pan (S/P washer) M3.5x6 1 0.5±0.05 (5±0.5)
Modem PCB ASSY Taptite cup S M3x6 SR 2 0.5±0.05 (5±0.5)
Joint cover side R Taptite bind B M4x12 1 0.7±0.1 (7±1)
Joint cover back Taptite bind B M4x12 2 0.7±0.1 (7±1)
Document scanner unit Taptite cup B M3x10 4 0.45±0.05 (4.5±0.5)
Key PCB hold Taptite bind S M3x5 1 0.45±0.05 (4.5±0.5)

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
