Brother MFC-9330CDW Service Manual

1-11
Confidential
1.5 Paper
1.5.1 Paper handling
Specifications are subject to change without notice.
1.5.2 Media specifications
*1
When you print on glossy paper, set only a single sheet on the manual feed slot.
*2
Legal size paper is not available in some regions outside U.S.A. and Canada.
Specifications are subject to change without notice.
1.5.3 Type and size of paper
The machine loads paper from the installed paper tray or the manual feed slot.
The names for the paper trays in the printer driver as follows:
Specifications are subject to change without notice.
Model
DCP-
9020CDN
DCP-
9020CDW
MFC-
9130CW
MFC-
9140CDN
MFC-
9330CDW
MFC-
9340CDW
Paper Input
Paper tray
250 sheets
Manual feed
slot
1 sheet
ADF 35 sheets
Paper
Output
Face-down 100 sheets (80 g/m
2
)
Face-up 1 sheet (Straight paper path)
2-sided Yes
N/A Yes
Model All models
Media type
Paper tray
Plain Paper, Thin Paper, Recycled Paper
Manual feed
slot
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper,
Bond paper, Label, Envelope, Env. Thin, Env.Thick, Glossy Paper
*1
2-sided Plain Paper, Thin Paper, Recycled Paper
ADF Plain Paper, Recycled Paper
Media weight Paper tray 60 to 105 g/m
2
(16 to 28 lb)
Manual feed
slot
60 to 163 g/m
2
(16 to 43 lb)
2-sided 60 to 105 g/m
2
(16 to 28 lb)
ADF 64 to 90 g/m
2
(17 to 24 lb)
Media size Paper tray
A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal
*2
, Folio
Manual feed
slot
Width: 76.2 to 216 mm (3.0 to 8.5 inch)
Length: 116 to 355.6 mm (4.57 to 14 inch)
2-sided Letter, Legal
*2
, Folio (for the U.S.A.),
A4 (for Europe, Asia, Oceania, China)
ADF Width 147.3 to 215.9 mm (5.8 to 8.5 inch)
Length 147.3 to 356.0 mm (5.8 to 14 inch)
The name for the paper trays The name for the paper trays in the printer driver
Paper tray Tray 1
Manual feed slot Manual

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
