Brother MFC-9330CDW Service Manual

2-115
Confidential
4.11.4 Wrinkles
<User Check>
- Check whether the document guide matches the document size.
- Check whether the document does not curl.
4.11.5 Document size cannot be correctly detected
<User Check>
- Check whether the document size is out of the specifications.
Step Cause Remedy
1 Document separate roller
worn out
Replace the document separate roller ASSY.
2 Document feed roller worn
out
Replace the document feed roller ASSY2.
Step Cause Remedy
1 Document scanning position
actuator catching on some
position
Re-assemble the document scanning
position actuator.
2 ADF motor failure Replace the ADF motor ASSY.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
