Brother MFC-9330CDW Service Manual

1-13
Confidential
1.8 FAX (Only for the models with FAX function)
Specifications are subject to change without notice.
1.9 Copy
Specifications are subject to change without notice.
Specifications are subject to change without notice.
Model
DCP-
9020CDN
DCP-
9020CDW
MFC-
9130CW
MFC-
9140CDN
MFC-
9330CDW
MFC-
9340CDW
Modem Speed
N/A 33,600 bps (FAX)
Transmission speed N/A Approximately 2 seconds
(ITU-T Test Chart #1, Std resolution, JBIG)
ITU-T group N/A Super G3
Color FAX Sending N/A
Receiving N/A
Internet FAX
(ITU T.37 simple mode)
N/A Yes (Download only)
Model DCP-9020CDN
DCP-9020CDW
Copy Speed (A4/Letter) Monochrome/Full Color: Up to 18/19 ppm
(for the U.S.A., Europe)
Monochrome/Full Color: Up to 22/23 ppm (for China)
First copy
out time
From Ready
mode and
Paper tray
Monochrome/Full Color: Less than 19/22 seconds
From Sleep
mode and
Paper tray
Monochrome/Full Color: Less than 35/38 seconds
Resolution 600 x 600 dpi
Auto duplex scanning copy N/A
Model
MFC-9130CW MFC-9140CDN MFC-9330CDW MFC-9340CDW
Copy Speed (A4/Letter) Monochrome/
Full Color: Up
to 18/19 ppm
Monochrome/Full Color: Up to 22/23 ppm
First copy
out time
From Ready
mode and
Paper tray
Monochrome/Full Color: Less than 19/22 seconds
From Sleep
mode and
Paper tray
Monochrome/Full Color: Less than 35/38 seconds
Resolution 600 x 600 dpi
Auto duplex scanning copy N/A Yes

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
