Brother MFC-9330CDW Service Manual

2-124
Confidential
4.14.7 Memory related failure
4.14.8 Printing related failure
<User Check>
- Check if the maximum number of pages that can be printed is exceeded.
4.14.9 The USB interface does not work
<User Check>
- Check if the data is supported device.
- Replace the device and check if the interface works.
- Reduce the data in the USB flash memory.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 USB host PCB harness
connection failure
Check the harness connection of the USB
host PCB and reconnect it.
2 USB host PCB failure Replace the USB host PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
