Brother MFC-9330CDW Service Manual

4-11
Confidential
6. IF YOU REPLACE THE DOCUMENT
SCANNER UNIT, ADF UNIT (DUPLEX
SCANNING MODEL ONLY) OR CIS UNIT
■ What to do when replacing the document scanner unit, ADF unit or CIS unit
- Check of Main Firmware Version
- Acquisition of White Level Data (Function code 55)
6.1 Check of Main Firmware Version
Refer to "1.1.1 Checking firmware version" in this chapter and check the version of the main
firmware. If the main firmware is not the latest version, install the firmware.
6.2 Acquisition of White Level Data (Function code 55)
Perform the acquisition of white level data in accordance with "1.4.18 Acquisition of white level
data and setting of CIS scanning area" in Chapter 5.
Note:
If the firmware is not the latest version and it does not support the CIS unit, the scanned
image becomes all black.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
