Brother MFC-9330CDW Service Manual

2-112
Confidential
4.10.5 Low-voltage power supply PCB failure
4.10.6 Modem PCB failure
Step Cause Remedy
1 Harness connection failure of
the low-voltage power supply
PCB
Check the harness connection of the
low-voltage power supply PCB and
reconnect it.
2 Low-voltage power supply
PCB failure
Replace the low-voltage power supply PCB
ASSY and reset the irregular power supply
detection counter.
3 Main PCB failure Replace the main PCB ASSY.
Note:
The irregular power supply detection error (Error code 0900) occurs when there is a large
distortion of the power supply voltage supplied to the machine. In this case, if the same
power supply is used, the same error might occur again even if the low-voltage power sup-
ply PCB ASSY is replaced. For this reason, be sure to ask the user to rearrange the instal-
lation environment.
Step Cause Remedy
1 Harness connection failure of
the modem PCB.
Check the harness connection of the modem
PCB and reconnect it.
2 Modem PCB failure Replace the modem PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
