Brother MFC-9330CDW Service Manual

5-60
Confidential
1.4.32 Display of device log information (Function code 80)
<Function>
This function allows you to display log information on the LCD.
<Operating procedure>
(1) Press the 8 and 0 keys in this order in the initial state of the maintenance mode.
"USB:********" is displayed on the LCD.
(********* represents the serial number of the machine.)
(2) Each time you press the key, a different item is displayed.
Press the key to go back to the previous item.
(3) Press the Stop key to return the machine to the initial state of the maintenance mode.
LCD Description
USB:000G8J000166 Serial number
*1
MAC:008077112233
*2
MAC Address
PCB:911309123456 Main PCB serial number
CTN_ERM:78% Amount of remaining cyan toner estimated from coverage
CTN_RRM:67% Amount of remaining cyan toner estimated from the number of
developer rotations
MTN_ERM:78% Amount of remaining magenta toner estimated from coverage
MTN_RRM:67% Amount of remaining magenta toner estimated from the number of
developer rotations
YTN_ERM:78% Amount of remaining yellow toner estimated from coverage
YTN_RRM:67% Amount of remaining yellow toner estimated from the number of
developer rotations
KTN_ERM:87% Amount of remaining black toner estimated from coverage
KTN_RRM:67% Amount of remaining black toner estimated from the number of
developer rotations
CDRM_PG:00000000 Number of pages printed with cyan drum
MDRM_PG:00000000 Number of pages printed with magenta drum
YDRM_PG:00000000 Number of pages printed with yellow drum
KDRM_PG:00000000 Number of pages printed with black drum
PFK1_PG:00000000 Number of pages where PF kit 1 has been used
FUSR_PG:00000000 Number of pages printed on fuser unit
BELT_PG:00000000 Number of pages printed on belt unit
TTL_PG:00000000 Total number of pages printed
TTL_CO:00000000 Total number of color pages printed
TTL_MO:00000000 Total number of monochrome pages printed
TTL_CI:00000000 Total number of cyan pages printed
TTL_MI:00000000 Total number of magenta pages printed
TTL_YI:00000000 Total number of yellow pages printed
TTL_KI:00000000 Total number of black pages printed

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
