Brother MFC-9330CDW Service Manual

5-61
Confidential
TTLCOPY:00000000 Number of copy pages
CL_COPY:00000000 Number of color copy pages
MN_COPY:00000000 Number of monochrome copy pages
TTLPCPT:00000000 Number of PC prints made
CL_PCPT:00000000 Total number of PC color printed pages
MN_PCPT:00000000 Total number of PC monochrome printed pages
TTLFAX:00000000 Number of List/FAX outputs made
CL_FAX:00000000 Total number of color List/FAX printed pages
MN_FAX:00000000 Total number of monochrome List/FAX printed pages
CCVRGUSI:4.32% Average coverage of cyan toner cartridge in use
CCVRGACC:3.47% Accumulated average coverage of cyan toner cartridge
MCVRGUSI:4.32% Average coverage of magenta toner cartridge in use
MCVRGACC:3.47% Accumulated average coverage of magenta toner cartridge
YCVRGUSI:4.32% Average coverage of yellow toner cartridge in use
YCVRGACC:3.47% Accumulated average coverage of yellow toner cartridge
KCVRGUSI:4.32% Average coverage of black toner cartridge in use
KCVRGACC:3.47% Accumulated average coverage of black toner cartridge
CDRUM:00000000 Number of cyan drum rotations
MDRUM:00000000 Number of magenta drum rotations
YDRUM:00000000 Number of yellow drum rotations
KDRUM:00000000 Number of black drum rotations
CTN_RND: 00000000 Number of cyan developer roller rotations
MTN_RND: 00000000 Number of magenta developer roller rotations
YTN_RND: 00000000 Number of yellow developer roller rotations
KTN_RND: 00000000 Number of black developer roller rotations
MN_PG:00000000 Number of pages printed on paper fed from manual feed slot
TR1_PG:00000000 Number of pages printed on paper fed from paper tray
DX_PG:00000000 Number of sheets where two-sided are printed
A4+LTR:00000000 Total of pages printed on A4 and letter size paper
LG+FOL:00000000 Total of pages printed on legal and folio size paper
B5+EXE:00000000 Total of pages printed on B5 and EXE size paper
ENVLOP:00000000 Number of pages printed on envelopes
A5 :00000000 Number of pages printed on A5 size paper
OTHER :00000000 Total of pages printed on paper other than the above
PLTNRE:00000000 Total of pages printed on plain, thin, and recycled paper
TKTRBD:00000000 Total of pages printed on thick, thicker paper and bond paper
ENVTYP:00000000 Total of pages printed on envelopes, envelopes (thick), and
envelopes (thin)
LABEL:00000000 Number of pages printed on label
LCD Description

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
