Brother MFC-9330CDW Service Manual

5-62
Confidential
HAGAKI:00000000 Number of pages printed on post card
GLOSSY:00000000 Number of pages printed on glossy paper
TTL_JAM:00000000 Total of jammed sheets
MN_JAM:00000000 Number of sheets jammed in the manual feed slot
TR1_JAM:00000000 Number of sheets jammed in the paper tray
IN_JAM:00000000 Number of sheets jammed inside the machine
RE_JAM:00000000 Number of sheets jammed in paper eject section and back cover
DX_JAM:00000000 Number of sheets jammed during two-sided printing
POWER:00000375 Total hours of current conduction
PWRCNT:00000000 Number of times that the power is turned ON
MACERR_01:0000
*3
Machine error history (Past 10 error history)
CTN_CH:0000
*4
Number of times that the cyan toner cartridge has been replaced
MTN_CH:0000
*4
Number of times that the magenta toner cartridge has been
replaced
YTN_CH:0000
*4
Number of times that the yellow toner cartridge has been replaced
KTN_CH:0000
*4
Number of times that the black toner cartridge has been replaced
CDRM_CH:0000
*4
Number of times that the cyan drum unit has been replaced
MDRM_CH:0000
*4
Number of times that the magenta drum unit has been replaced
YDRM_CH:0000
*4
Number of times that the yellow drum unit has been replaced
KDRM_CH:0000
*4
Number of times that the black drum unit has been replaced
WTNR_CH:0000
*4
Number of times that the waste toner box has been replaced
BELT_CH:0000 Number of times that the belt unit has been replaced
FUSR_CH:0000
*4
Number of times that the fuser unit has been replaced
PFK1_CH:0000
*4
Number of times that the PF kit 1 has been replaced
CTN_PG1:00000000 Number of pages printed from the currently installed cyan toner
cartridge
CTN_PG2:00000000 Number of pages printed from the previous installed cyan toner
cartridge
MTN_PG1:00000000 Number of pages printed from the currently installed magenta
toner cartridge
MTN_PG2:00000000 Number of pages printed from the previous installed magenta
toner cartridge
YTN_PG1:00000000 Number of pages printed from the currently installed yellow toner
cartridge
YTN_PG2:00000000 Number of pages printed from the previous installed yellow toner
cartridge
KTN_PG1:00000000 Number of pages printed from the currently installed black toner
cartridge
KTN_PG2:00000000 Number of pages printed from the previous installed black toner
cartridge
WTNR_PG:00000000 Number of pages printed from the waste toner box
LCD Description
