Brother MFC-9330CDW Service Manual

5-69
Confidential
2. OTHER SERVICE FUNCTIONS
2.1 Toner Manual Reset Function
This function is to manually perform the same operation as the one when a toner cartridge is
replaced with a new one. The purpose of this function is to provide a means to resolve an
error when a new toner cartridge cannot be recognized by the machine, and the toner life
display fails to be cleared.
<Operating procedure>
(1) Press the "Fax" icon on the LCD to illuminate the keys that have stayed OFF on the
control panel, and identify the location of the * key.
(2) Press the Home key to return the machine to the ready state.
(3) Open the joint cover ASSY. Check that the message "Cover is Open" is displayed on the
entire surface of the LCD. Hold down the * key for 5 seconds or longer.
(4) "Reset Menu" is displayed on the LCD. Referring to the following list, select the toner
cartridge you want to reset.
(5) When "Reset? Yes No" appears on the LCD, press Yes key. "Accepted" appears on the
LCD, and the manual reset of the toner cartridge is performed. When the machine
finishes resetting the toner cartridge, it returns to "Reset Menu".
(6) Press the Home key to return the machine to the ready state.
(7) Close the joint cover ASSY.
Note:
Though the * key does not light up, continue holding down the key.
LCD Measure
K.TNR-STD Standard black toner manual reset
K.TNR-STR Starter black toner manual reset
C.TNR-STD Standard cyan toner manual reset
C.TNR-HC High yield cyan toner manual reset
C.TNR-STR Starter cyan toner manual reset
M.TNR-STD Standard magenta toner manual reset
M.TNR-HC High yield magenta toner manual reset
M.TNR-STR Starter magenta toner manual reset
Y.TNR-STD Standard yellow toner manual reset
Y.TNR-HC High yield yellow toner manual reset
Y.TNR-STR Starter yellow toner manual reset
