Brother MFC-9330CDW Service Manual

5-25
Confidential
1.4.13 PC print function setting (Function code 43)
<Function>
This function is used to change the settings of the various print functions summarized in the
table below.
<Operating procedure>
(1) Press the 4 and 3 keys in this order in the initial state of the maintenance mode.
"Manual Feed" is displayed on the LCD.
(2) Press the or key to select the function you want to set and press the SET key.
(3) For fixed parameters (On/Off, etc.), press the or key, or change the parameter
using the numeric keys. And press the SET key.
For parameters requiring numerical value entry, directly input a numeric value from the
ten-key pad and press the SET key.
(4) Press the Stop key to return the machine to the initial state of the maintenance mode.
■ Function setting
LCD Detail description Set value
Initial
value
Manual Feed Switching of the Manual Feed On/Off Off
Resolution Resolution to print 300/600/1,200 dpi 600
Toner Save Switching of the Toner Save On/Off Off
Density Switching of the Density level -6 to 6 0
JB-Can Time Setting of the time until the
host time-out at the Job
Cancel
0 to 225 (seconds) 4
Sleep Time Setting of the time until enter
the Sleep Mode
0 to 99 (minutes) 5
Page Protection Switching of the protection of
the page memory
Off/Letter/A4/Legal/Auto Off
Emulation Switching of the emulation Auto/HP/PS Auto
Auto I/F Time Switching of the I/F open time 1 to 99 (seconds) 5
Media Type Switching of the paper type Thin/Plain/Thick/Thicker/
Trancparency/Recycled/
Bond/Envlopes/EnvThin/
EnvThick
Plain
or
Thin
Paper Size Switching of the area of
develop the image
Letter/Legal/A4/Executive/
ISOB5/JISB5/A5/ISOB6/
A6/Monarch/C5/COM10/
DL/DLL/A4Long/Hagaki/
Folio
Letter
or
A4
Copies Switching of the print copies 1 to 99 (pages) 1
Orientation Switching of the print direction PortLait/Landscape Portlait
P-Pos X-Offset Switching of the offset print
position of the landscape
orientation
-500 to 500 (1/300 dpi) 0
