Brother MFC-9330CDW Service Manual

5-15
Confidential
* For more information on the worker switch, refer to Reference.
<Operating procedure>
(1) Press the 1 and 0 keys in this order in the initial state of the maintenance mode.
"WSW00" is displayed on the LCD.
(2) Enter the number of worker switch to change.
The following is displayed on the LCD.
(3) Move the cursor to the selector you want to change with the < and > keys, and change the
value by pressing the 1 or 0 key.
(4) When you finish changing the value, press the SET key. This operation saves the newly
entered selector values onto the EEPROM and readies the machine for accepting a
worker switch number (WSW00).
(5) When worker switch setting is completed, press the Stop key to return the machine to the
initial state of the maintenance mode.
WSW73 Reserved (Change of the setting is prohibited)
WSW74 ADF stop control
WSW75 Paper ejecting distance of the switch back
WSW76 The limited number of the documents in reverse for paper ejection of the
one-sided scanning from ADF
WSW77 The limited number of the documents in reverse for paper ejection of the
two-sided from ADF
WSW78 Recording stop function when the drum reaches the end of life
WSW79 Function setting 27
WSW80 Copying speed control function
WSW81 Changing emulation function enable/disable setting
WSW82 AirPrint Icon No. setting
Memo:
- To cancel this operation and return the machine to the initial state of the maintenance
mode during the above procedure, press the Stop key.
- If there is a pause of more than one minute after a single-digit number is entered for
double-digit worker switch numbers, the machine will automatically return to the initial
state of the maintenance mode.
WSW No. Function
Selector 1 Selector 8

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
