2-6
Confidential
2.1.2 ADF unit/Document scanner unit
Fig. 2-2
* The one-sided scanning model is not provided with the second side document hold, second side CIS unit, second side document scanning position
actuator and document feed roller ASSY1 which are shown in the above figure.
First side CIS unit
Second side document
Document detection
Document ejection roller
ADF document output support flap
ADF document support
Document guide
Document pick-up roller
Document separate roller
ADF separation pad
Document feed
Second side CIS unit
Document feed
roller ASSY2
roller ASSY1
actuator
scanning position actuator
Second side
document hold
First side document
hold
Document pinch roller
First side document
scanning position
actuator
