Brother MFC-9330CDW Service Manual

5-3
Confidential
1.3 List of Maintenance-mode Functions
Function
code
Function Refer to:
01 EEPROM parameter initialization 1.4.1 (5-5)
05 Printout of scanning compensation data 1.4.2 (5-6)
06 Placement of CIS unit in position for transportation 1.4.3 (5-11)
08 ADF performance test 1.4.4 (5-11)
09 Monochrome image quality test pattern 1.4.5 (5-12)
10 Worker switch (WSW) setting 1.4.6 [1] (5-13)
11 Printout of worker switch (WSW) data 1.4.6 [2] (5-16)
12 Operation check of LCD 1.4.7 (5-17)
13 Operational check of control panel key 1.4.8 (5-18)
25 Software version check 1.4.9 (5-19)
32 Operational check of sensors 1.4.10 (5-20)
33 LAN connection status display 1.4.11 (5-22)
41 Backup of machine information 1.4.12 (5-23)
43 PC print function setting 1.4.13 (5-25)
45 Changing return value of USB No./Switching Dither Pattern/
Switching of ON/OFF of DirectPrint Color mode-Improve
Gray Color/Switching of timing to execute Auto Registration/
Adjusting left-end print start position on second side in
duplex printing (2-sided printing model only)
1.4.14 (5-29)
52 Set country/language 1.4.15 (5-32)
53 Transfer of received fax data and log information 1.4.16 (5-33)
54 Fine adjustment of scan positions 1.4.17 (5-35)
55
Acquisition of white level data and setting of CIS scanning area 1.4.18 (5-36)
57 Motor reset 1.4.19 (5-37)
61 Adjustment of touch panel 1.4.20 (5-38)
66 Adjustment of color registration
(Adjustment of inter-color position alignment)
1.4.21 (5-39)
67 Print test 1.4.22 (5-42)
68 LED test pattern print 1.4.23 (5-45)
69 Frame pattern print (One-sided) 1.4.24 (5-47)
70 Frame pattern print (Two-sided) 1.4.25 (5-48)
71 Color test pattern 1.4.26 (5-49)
72 Sensitivity adjustment of density sensor 1.4.27 (5-52)
73 Continuous adjustments of density and registration sensor 1.4.28 (5-53)
74
Setting by country 1.4.29 (5-54)
77
Printout of maintenance information 1.4.30 (5-56)
78
Operational check of fans 1.4.31 (5-59)

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
