Brother MFC-9330CDW Service Manual

2-12
Confidential
3. ERROR INDICATIONS
This machine includes a self-diagnosis function. If the machine does not work normally it
judges that an error has occurred, and indicates the corresponding error message on the LCD,
which in turn helps the service personnel to quickly find out the problem.
3.1 Error Codes
The shaded errors hardly occur under normal use. They may be caused by noise around the
installation site, variation in power supply voltage, or software failure.
Error
codes
Problem
Refer
to:
0100 ASIC error or motor driver error
occurred.
2-34
0201 Synchronization signal from the
main motor cannot be detected.
Or the main motor speed is
unstable after a set period of
time.
2-34
0202 Synchronization signal from the
process motor cannot be
detected. Or the process motor
speed is unstable after a set
period of time.
2-34
0203 ---
0204 ---
0205 ---
0206 ---
0207 ---
0208 ---
0209 ---
0300 ---
0401 ---
0402 ---
0501 The center thermistor of the
fuser unit does not reach the
specified temperature within the
specified time.
2-35
0502 The center thermistor of the
fuser unit does not reach the
specified temperature within the
specified time.
2-35
0503 The center thermistor of the
fuser unit detected a
temperature higher than the
specified value.
2-35
0504 After the center thermistor of the
fuser unit was normally heated, it
detected a temperature lower
than the specified value.
2-35
0505 The center thermistor of the
fuser unit detected a
temperature rise greater than the
specified value within a set
period of time.
2-35
0506 The center thermistor of the
fuser unit detected a
temperature fall greater than the
specified value within a set
period of time.
2-35
0507 ---
0508 ---
0509 ---
050A The center thermistor or side
thermistor of the fuser unit
detected some temperature error
in the hardware.
2-36
Error
codes
Problem
Refer
to:
