Brother MFC-9330CDW Service Manual

2-13
Confidential
050B When the temperature of the
center thermistor of the fuser unit
is lower than the idle
temperature, the side thermistor
of the fuser unit detected a
temperature higher than the
specified value.
2-36
050C When the temperature of the
center thermistor of the fuser unit
is higher than the idle
temperature, the side thermistor
of the fuser unit detected a
temperature lower than the
specified value.
2-36
050D ---
050F ---
0700 ---
0800 Error occurred in the internal
temperature sensor.
2-37
0900 Machine detected that supplied
power was unstable.
2-37
0A01 ---
0A02 The main fan failure was
detected.
2-38
0B01 Error in the high-voltage power
supply PCB ASSY while the
machine is in operation.
2-38
0B02 Error in the high-voltage power
supply PCB ASSY in the ready
state.
2-38
0C00 Error occurred in the density
sensor.
2-39
0D01 ---
0D02 ---
0D03 ---
0D04 ---
0E00 ---
Error
codes
Problem
Refer
to:
1001 ---
1002 ---
1003 The registration mark L PCB is
dirty and cannot normally receive
reflected light.
2-39
1004 The registration mark R PCB is
dirty and cannot normally receive
reflected light.
2-39
1100 ---
1300 ---
1400 ---
1C00 ---
1D01 Communication error occurred in
the LED ASSY (Black).
2-40
1D02 Communication error occurred in
the LED ASSY (Yellow).
2-40
1D03 Communication error occurred in
the LED ASSY (Magenta).
2-40
1D04 Communication error occurred in
the LED ASSY (Cyan).
2-40
1E01 Access is unavailable between
the main PCB and LED control
PCB.
2-41
1E02 Read/Write is unavailable
between the main PCB and LED
control PCB.
2-41
2001 ---
2002 ---
2003 ---
2004 ---
2005 ---
2006 ---
2101 ---
Error
codes
Problem
Refer
to:

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
