Brother MFC-9330CDW Service Manual

2-40
Confidential
■ Error code 1D01
Communication error occurred in the LED ASSY (Black).
Error code 1D02
Communication error occurred in the LED ASSY (Yellow).
Error code 1D03
Communication error occurred in the LED ASSY (Magenta).
Error code 1D04
Communication error occurred in the LED ASSY (Cyan).
<User Check>
- Install the toner cartridge.
Print Unable 1D
Turn the power off and then back on again.
Print Unable 1D
Turn the power off and then back on again.
Print Unable 1D
Turn the power off and then back on again.
Print Unable 1D
Turn the power off and then back on again.
Step Cause Remedy
1 Connection failure of the flat
cable of each LED ASSY
Check the flat cable connection of each
LED ASSY and reconnect it.
2 LED control PCB harness
connection failure
Check the LED control PCB harness
connection and reconnect it.
3 Flat cable failure of each LED
ASSY.
Replace the flat cable of each LED ASSY.
4 Each LED ASSY failure Replace the each LED ASSY.
5 LED control PCB failure Replace the LED control PCB ASSY.
6 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
