Brother MFC-9330CDW Service Manual

5-33
Confidential
1.4.16 Transfer of received fax data and log information (Function code 53)
<Function>
This function allows you to transfer received FAX data to another machine when the machine
cannot print the received data due to the printing mechanism failure. Activity reports,
communication lists, and machine log information can be also transferred.
<Operating procedure>
(1) Press the 5 and 3 keys in this order in the initial state of the maintenance mode.
"FAX TRANSFER" is displayed on the LCD.
- To check the number of received files, press the 1 key.
"1.NO. OF JOBS" is displayed on the LCD.
Press the SET key, and the number of received files appears, just as "NO. OF. JOBS: 10".
- To transfer the activity report only, press the 2 key.
"2.ACTIVITY" is displayed on the LCD.
- To transfer received files (together with the activity report), press the 3 key.
"3.DOCUMENTS" is displayed on the LCD.
Note that if there is no received file, the "NODOCUMENTS" appears on the LCD.
- To transfer the communication list for the latest communication, press the 4 key.
"4.COM.LIST (NEW)" is displayed on the LCD.
- To transfer the communication list for last three errors, press the 5 key.
"5.COM.LIST (ERR3)" is displayed on the LCD.
-
To transfer the maintenance information (the list in Function code 77), press the 6 key.
"6.MNT77 LIST" is displayed on the LCD.
(2) With the "2.ACTIVITY," "3.DOCUMENTS," "4.COM.LIST (NEW)," "5.COM.LIST (ERR3)"
or "6.MNT77 LIST" being displayed, press the SET key.
"ENTER NO. & SET" is displayed on the LCD.
(3) Enter the telephone number of the receiver machine and press the SET key again.
(4) The machine displays the "ACCEPTED" for approximately two seconds and starts dialing
to transfer data.
Note:
- Up to 99 files can be transferred simultaneously. When you transfer 100 files or
more, perform the following procedure multiple times.
- If there are both color and monochrome data the monochrome data will be
transferred first. If the receiver machine does not support the color function, the
sender machine cannot transfer color data, resulting in an error.
Note:
- Be sure to type the telephone number with the numerical keys. No one-touch dialing
is allowed in this procedure.
- No station ID will be attached. A cover page and end page as shown on the next
page will be automatically attached, instead.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
