Brother MFC-9330CDW Service Manual

3-5
Confidential
Panel control PCB shield
plate cover
Taptite cup B M3x10 4 0.45±0.05 (4.5±0.5)
LCD hold plate Taptite cup B M3x10 3 0.45±0.05 (4.5±0.5)
Scanner top cover ASSY Taptite bind B M4x12 6 0.65±0.05 (6.5±0.5)
LED PCB cover Taptite cup S M3x8 SR 3 0.4±0.05 (4±0.5)
LED control PCB ASSY Taptite cup S M3x8 SR 2 0.4±0.05 (4±0.5)
Duplex tray Taptite bind B M4x12 2 0.7±0.05 (7±0.5)
Main PCB ASSY Taptite cup S M3x8 SR 3 0.7±0.1 (7±1)
Develop clutch gear cover Taptite cup S M3x8 SR 1 0.7±0.1 (7±1)
Flat cable guide Taptite cup S M3x8 SR 2 0.7±0.1 (7±1)
Main shield plate Taptite cup S M3x8 SR 2 0.7±0.1 (7±1)
LVPS FG harness Screw pan (S/P washer) M3.5x6 1 0.4±0.05 (4±0.5)
Process drive unit Taptite cup S M3x8 SR 2 0.7±0.05 (7±0.5)
Taptite bind B M4x12 7 0.7±0.05 (7±0.5)
Taptite pan (washer) B M4x12 DA 1 0.7±0.05 (7±0.5)
Main drive unit Taptite bind B M4x12 5 0.7±0.1 (7±1)
Inner front cover Taptite bind B M4x12 1 0.9±0.1 (9±1)
USB cover ASSY Taptite bind B M3x10 2 0.4±0.05 (4±0.5)
USB host PCB ASSY Taptite bind B M3x10 2 0.4±0.05 (4±0.5)
Paper feed unit Taptite bind B M4x12 4 0.8±0.1 (8±1)
Paper eject ASSY Taptite bind B M4x12 3 0.8±0.1 (8±1)
Back cover upper Taptite bind B M3x10 4 0.5±0.1 (5±1)
HVPS ground plate front Taptite cup S M3x8 SR 1 0.7±0.1 (7±1)
Taptite pan (washer) B M4x12 DA 1 0.6±0.05 (6±0.5)
HVPS ground plate rear
Taptite pan (washer) B M4x12 DA 1 0.6±0.05 (6±0.5)
High-voltage power
supply PCB ASSY
Taptite bind B M4x12 1 0.6±0.05 (6±0.5)
Cover plate Taptite bind B M4x12 2 0.8±0.1 (8±1)
Taptite bind S M3x5 1 0.5±0.1 (5±1)
Taptite pan (washer) B M4x12 DA 1 0.7±0.05 (7±0.5)
LVPS FG harness Screw pan (S/P washer) M3.5x6 1 0.4±0.05 (4±0.5)
LVPS plate lower
Taptite pan (washer) B M4x12 DA 6 0.8±0.1 (8±1)
Taptite cup S M3x8 SR 2 0.5±0.1 (5±1)
Location of screw Screw type Q' ty
Tightening torque
N
·m (kgf·cm)

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
