Brother MFC-9330CDW - Page 171

3-8
Confidential
GE1.5 to 2.0: FLOIL GE-676 (1.5 to 2.0 mm dia. ball)
BDX2.0 to 2.5: BDX313 (A) (2.0 to 2.5 mm dia. ball)
GE1.5 to 2.0
GE1.5 to 2.0
GE1.5 to 2.0
GE1.5 to 2.0
BDX2.0 to 2.5
BDX2.0 to 2.5
Document separate
Document feed roller
Document feed
Hinge ASSY L
Upper ADF chute
3 mm
3 mm
3 mm
3 mm
Document ejection roller
roller ASSY2
ASSY1
Lower ADF chute
roller ASSY
