3-77
Confidential
Fig. 3-91
(3) Disconnect the Connector from the ADF motor.
Fig. 3-92
Assembling Note:
When asembling the Drive frame ASSY, ensure that the Arm ASSY L2 are placed in the
positions as shown in the figure below.
Drive frame ASSY
Arm ASSY L2
Drive frame ASSY
ADF motor
Connector
