Brother MFC-9330CDW Service Manual

5-40
Confidential
■ Printing of misregistration correction chart
<Operating procedure>
(1) Press the 6 key twice in the initial state of the maintenance mode.
"REGISTRATION" is displayed on the LCD.
(2) Press the or key to display "PRINT CHART" on the LCD.
(3) Press the SET key. "PRINTING" is displayed on the LCD, and printing of misregistration
correction chart (refer to fig. 5-15 (P5-41)) is printed. When printing is finished, "PRINT
CHART" is displayed on the LCD.
(4) Press the Cancel key to return the machine to the initial state of the maintenance mode.
■ Adjustment of inter-color position alignment (manual)
<Operating procedure>
(1) Press the 6 key twice in the initial state of the maintenance mode.
"REGISTRATION" is displayed on the LCD.
(2) Press the or key to display "SET REGISTRATION" on the LCD.
(3) Press the SET key. "1. MAGENTA=0" is displayed on the LCD.
Using the printed misregistration correction chart, identify the numeric value whose color
is the darkest in the pattern of (1) (Magenta Left) shown in fig. 5-15 (P5-41).
Press the or key to display the identified numeric value.
(4)
Press the SET key, and enter each numeric value of the patterns (2) to (9) in the same way.
(5) When you enter the numeric value of the pattern (9) (Yellow Right), "COMPLETED" is
displayed on the LCD.
(6) Press the Cancel key to return the machine to the initial state of the maintenance mode.
■ Adjustment of inter-color position alignment including registration sensor
calibration (auto)
<Operating procedure>
(1) Press the 6 key twice in the initial state of the maintenance mode.
"REGISTRATION" is displayed on the LCD.
(2) Press the or key to display "ADD REGISTRATION" on the LCD.
(3) Press the SET key. "PLS WAIT 66-1" is displayed on the LCD and sensitivity adjustment
of registration sensor and adjustment of inter-color position alignment are performed
automatically.
(4) When this operation is completed without an error, "COMPLETED" is displayed on the LCD.
(5) Press the Cancel key to return the machine to the initial state of the maintenance mode.
Memo:
If the Adjustment of inter-color position alignment including registration sensor calibration
(auto) fails while being in process,
" ERROR 66-1 " is displayed on the LCD.
Refer to the error message list on next page for the troubleshooting.
