Brother MFC-9840CDW - Page 378

Confidential
5-18
Fig. 5-10
Fig. 5-11
MP PE sensor
MP registration front sensor
MP unit ASSY
MP PE/sensor PCB ASSY
Registration rear sensor
T1 registration front sensor
LT Paper feed frame unit
LT edge sensor
LT sensor
LT tray guide left rear ASSY
THM/HUM sensor
THM/HUM sensor
holder ASSY
Front cover
Develop press drive L ASSY
LT plate-up detection sensor
LT PE sensor
LT connector
A
DF unit
Document scanner unit
Document front sensor
A
DF document separation
sensor / Size sensor
A
DF document SB senso
r
Document rear sensor
FB unit home position sensor
FB cover sensor
