Battery
Installation
Each outboard requires its own starting battery.
Select a battery that meets or exceeds the mini-
mum requirements.
Minimum
12
Volt
Battery
Recommenda-
tions
• 360 CCA (465 MCA), 50 amp-hr minimum
Location
and
Preparation
Proper installation will prevent battery movement
while underway.
• Secure all batteries
in
protected locations.
•
Position battery
as
close to the outboard as
possible.
•
Battery location must provide access for peri-
odic maintenance.
• Use battery mounting trays or battery boxes
on
all battery installations.
•
Connections and terminals must be covered
with an
insulator.
•
Battery connections must be clean and free
from corrosion.
• Read and understand the safety information
supplied with the battery before installation.
ill
WARNING
ill
Keep the battery
connections
clean,
tight,
and
insulated
to
prevent
their
shorting
or
arcing
and
causing an
explosion.
If
the
bat-
tery
mounting
system
does
not
cover
the
connections,
install
protective
covers.
Check
often
to
see
that
connections
stay
clean and tight.
Connections
IMPORTANT:
Connect the battery positive (+)
cable to the battery positive (+) post FIRST. Con-
nect the battery negative
(-)
cable to the battery
negative
(-)
post
LAST.
Models 1
to
10 Ft.
(.3
to
3 m)
9.9/15
HP
10
Gauge
INSTALLATION
AND
PREDELIVERY
BOAT RIGGING
Install a starwasher
on
the threaded battery post.
Stack cables from the outboard, then cables from
accessories. Finish this connection with a hex nut.
Marine Style
Battery
Post
DR5103
1. Starwasher
2. Hex nut
3. Terminal Insulator
IMPORTANT:
Do not use wing nuts to fasten
ANY battery cables. Wing nuts can loosen and
cause
electrical system damage not covered
under warranty.
Tighten
all connections securely. Apply Triple-
Guard
grease to prevent corrosion.
Battery
Cable
Requirements
EvinrudelJohnson outboards are shipped with
stranded copper battery
cables for typical installa-
tions
in
which the starting battery is positioned
close to the transom.
Specialized outboard installations with extended
length battery cables require
an
increased wire
size. Refer to the
table below.
IMPORTANT:
Inadequate battery cables can
affect the performance of an outboard's high
amperage start circuit and the cranking speed
of
the outboard. DO NOT use aluminum wire cables.
Use ONLY AWG stranded copper wire cables.
11
to
15 Ft. 16
to
20 Ft.
(3.4
to
4.6 m) (4.9
to
6.1
m)
8 Gauge 6 Gauge
29
