MAX Operation & Service Manual 111MAX Operation & Service Manual Section 6: Maintenance & Service 111
1. Place machine in Operating Position with the covers open and the power supply on.
2. Go to the “Cleaning Diagnostics” screen in the “Maintenance” menu of the Tablet.
3. Lower the squeegee head so the sensor shows the squeegee is down and remove the waste
recovery tank.
4. Place the machine on the lane and push the machine out to the arrows.
5. Place the squeegee adjustment tool on the lane surface between the cloth and the squeegee
assembly with the “max” side facing up.
6. Slide the adjustment tool underneath the front of the squeegee assembly. If the tool does not t
at the “max” dimension then rotate it to the “min” adjustment and repeat. If the tool still does
not t, an adjustment is required.
7. Loosen the 2 pivot shaft mounting screws with the ½” wrench so the pivot shaft can move up or
down freely. Use the 7/16” socket with extension to raise and lower each side of the pivot shaft.
The 2 adjustment screws are located on either side of the electronic enclosure in the mid-frame.
The adjustment manages the overall height and balance left to right.
a. If the squeegee is too high, rotate the adjustment screws counter-clockwise to lower the
squeegee assembly.
b. If it’s too low, rotate the adjustment screws clockwise to raise the squeegee assembly.
NOTE: Whenrotatingtheadjustmentscrews,countthefullnumberofturnsoftheratchetto
ensurethattheassemblyisadjustedequallyonbothsides.
8. Tighten the 2 pivot shaft mounting screws using the ½” wrench.
9. Check the adjustment and repeat until the adjustment tool ts between the lane and squeegee
extrusion for either the min or max adjustment.
10. Replace the waste recovery tank.
11. Perform a clean only run to test the cleaning.
