3. Disconnect switch cables at connector plug, leaving the wires on the switches.
4. Remove the 2 screws that secure the switch to the mounting bracket using a 1/16” allen wrench.
NOTE:Theup/downswitchesaremountedbacktobackonthebracketandcanbe
distinguishedbythecoloroftheirwires;the“up”switchhasgreenandwhitecables,the
“down”switchhasblueandblackcables.
5. Remove switches.
6. Replace faulty switch.
7. Reconnect cables using the fast-on cable connectors.
8. Position switches on mounting bracket and replace and tighten screws that secure switches to
the bracket.
NOTE:Positionswitchesasclosetothecamaspossibletoensuregoodcontactwithswitches.
9. Connect Cable plug to harness.
10. Position the electronics enclosure in place, replace and tighten bolts that secure the electronic
enclosure to mounting brackets, and reconnect all cables.
Lubricating the Squeegee Lifting Assembly
Refer to Figure6-14.
1. Apply one drop of oil to each side of the bearings on the squeegee pivot arm.
2. Apply one drop of oil to the bearings on the squeegee lifting linkage connected to the cam for
the lifting motor and to the shaft connecting both squeegee pivot arms. The squeegee blade
is two sided and after one side has reached the end of its useful life, rotate the squeegee blade
to place the opposite edge in use. Expected life is 3 – 6 months per side for a 40 lane bowling
center; however, the wear is dependent on use and the condition of the lane surface.
