Error Messages - Table 7-11:
An error occurred during operation.
The Duster cloth is not working properly. The Duster cloth up sensor did not activate.
NOTE:VerifyerrorsourcethroughTabletdiagnostics.
What you may observe Potential problem Action
1. Duster cloth is down and did
not raise
1. Duster cloth not attached properly to the
waste core
2. Duster cloth supply roll turns easily
3. Duster cloth supply roll is not able to turn
4. Broken wire or loose connection at
switch, motor or at the electronic enclosure
5. Failed switch
6. Failed duster motor
7. Plastic plug on end of duster cloth waste
core is not properly engaged into drive hub.
1. Check attachment
2. Tighten clutch torque bolt
See Adjusting the duster clutch for more
information
3. Option 1: Loosen clutch torque bolt
See Adjusting the duster clutch for more
information
Option 2: Replace duster clutch
4. Repair connection
5. Verify switch function using Tablet diag-
nostics and replace if necessary
6. Verify motor function using Tablet diag-
nostics and replace if necessary
7. Check that duster cloth is not restricting
the plastic plug from full engagement with
roll pin in drive hub. Also check staples are
not loose between plug and core.
Error Message - Table 7-12:
An error occurred during operation.
The End of Lane Sensor was not received when expected. Reset the lane length counter on the counters
screen, then check the End of Lane Sensor.
NOTE: Theabovemessageisgeneratedwhenthemachineforwardtravelstopsandreverses
beforetheendofthepindeck.
NOTE:VerifyerrorsourcethroughTabletdiagnostics.
What you may observe Potential problem Action
1. LED on end of lane sensor is
not lit
1. Improper Height
2. Improper Sensitivity Adjustment
3. Pin deck out of spec, defective pin spot,
or missing lane plug
4. Failed Sensor
5. Pushing the machine too far from the
foul line
1. Adjust Height
See Adjusting the end-of-lane sensor for
more information
2. Adjust Sensitivity
See Adjusting the end-of-lane sensor for
more information
3. Option 1: Adjust or repair pin deck
Option 2: Replace pin spot or missing lane
plug
4. Verify sensor function using Tablet diag-
nostics and replace if necessary
5. Reset counter and start the machine as
close to the foul line as possible
