MVX250i E, MVX200i E, MVX200 E
GENERAL DESCRIPTION OF PRODUCT
27
b. Audio signals
Types of signals Stereo audio signal
Impedance Max. 3 kΩ
Signal level −10 dBv
Frequency characteristic 60 Hz to 16 kHz (Range between 1 kHz standard ±3 dB)
Audio signal S/N
Built-in microphone input Min. 48 dB
External microphone input Min. 48 dB (However, the MVX200i E, MVX200 E model does not have an external micro-
phone input terminal.)
6-7-3 S-Video terminal
Signal configuration PAL Y/C separated video signal
Video signals 1 Vp-p (brightness + synchronization signal)
Color signal 0.3 Vp-p (Color burst signal)
Impedance 75 Ω
Signal level 0.3 Vp-p (Color burst signal)
Brightness signal S/N Min. 45 dB
Horizontal resolution
Self recording / playback Conforms to camera EE OUT
Camera EE OUT Max. approx. 530 TV lines (screen center)
6-7-4 Headphone terminal φ 3.5 mm stereo mini jack
Output impedance 100 Ω
Signal level −25 dBv (with 16 Ω load at maximum volume)
6-7-5 USB terminal Supports USB2.0 FullSpeed class
USB device class Independent class, PTP class, mass storage class, audio class, video class
Compatible computer systems Windows : IBM PC/AT compatible, NEC PC98-NX Series
Macintosh : Power Macintosh, PowerBook, iMac, iBook
PC operating system Windows : Windows 98, Windows 98SE, Windows ME, Windows 2000, Windows XP
Macintosh : Mac OS 9 or later
6-8 Memory card system
6-8-1 Types of memory cards used SD memory card, Multimedia card
6-8-2 Recordable image types
a. Still image JPEG recording
In Camera mode When [ ] Fine], or [ ] Normal] is selected for [PHOTO REC] on the [CAM SET UP]
menu, still images can be recorded on the memory card by operating the photo button while
motion video is being recorded on the tape. (Tape simultaneous recording function: VGA still
images)
In Card Recording mode Still image is recorded using the Photo button (image size and image quality are selectable).
Writing in Progress warning is displayed in the EVF/ LCD.
During playback mode Still image is recorded using the photo button during tape playback (pressed halfway down for
still image playback and pressed all the way down for recording). (VGA still images)
Also, DV input images (when no tape loaded or loaded tape is stopped) can be recorded by
pressing the photo button (pressing halfway captures still image of the DV input, pressing all the
way down records the image).
b. Motion video AVI (Video data: Motion JPEG / Audio data: WAVE (monoaural))
Records only camera images during Card Record mode and from tape during VCR mode (re-
cording from DV input,
AV input and S- Video input are disabled).
Image quality in recording onto card from tape / DV input
Source Source recording system Image recorded on card
Tape / DV input Progressive or frame motion video recording Progressive or frame image
Tape / DV input Normal motion video recording Simple pure frame image
Analog AV input Normal motion video recording Field image
