MVX250i E, MVX200i E, MVX200 E
GENERAL DESCRIPTION OF PRODUCT
34
6-12 Terminal
6-12-1 DV terminal Special 4-pin (IEEE1394 compatible) ; input and output
(MVX200i E, MVX200 E model has output only.)
6-12-2 S-Video terminal 4-pin mini-DIN ; input and output
6-12-3 AV (Audio / Video) terminal φ 3.5 mm 4-pole pin jack (yellow) ; input / output
(output only on MVX200i E, MVX200 E model) ; Also serves as headphone terminal
6-12-4 External microphone input Included (However, except for MVX200i E, MVX200 E model)
terminal
6-12-5 Headphone terminal φ 3.5 mm stereo mini-jack (also serves as AV terminal)
6-12-6 Memory card connection Special multi-pin
terminal
6-12-7 Battery terminal Special 3-pin
6-12-8 DC IN terminal φ 3.4 mm jack (for connecting CA-570)
6-12-9 USB terminal 5-pin (mini-B Receptacle)
7 Power supply
7-1 Input power supply 7.4V DC (battery pack), 8.4V DC (DC IN).
7-2 Power consumption During recording: Approx. 2.6 W (using EVF) ; Approx. 3.3 W (using LCD monitor)
During playback : Approx. 2.8 W (using LCD monitor)
8 Dimensions (W × H × D) Approx. 74 × 78 × 130 mm (2.9 × 3.1 × 5.1 in) (Protrusions excluded)
Approx. 79 × 78 × 130 mm (3.1 × 3.1 × 5.1 in) (Maximum width with protrusious)
9 Weight
9-1 Body MVX250i E : Approx. 500 g (1.1 lb)
MVX200i E, MVX200 E : Approx. 500 g (1.1 lb)
9-2
Total equipped weight
MVX250i E : Approx. 560 g (1.2 lb)
MVX200i E, MVX200 E : Approx. 560 g (1.2 lb)
(Including NB-2LH, DVM-E30, lens cap, lithium coin battery, and SDC-8M)
MVX250i E : Approx. 600 g (1.3 lb)
(Including BP-2L14, DVM-E30, lens cap, lithium coin battery, and SDC-8M)
10 Temperature and humidity requirements
10-1 Temperature and humidity requirements for performance
0 to 40°C, 85% (relative humidity)
10-2 Temperature and humidity requirements for operation
−5 to 40°C, 65% (relative humidity)
