CAPINTEC, INC. CAPRAC
®
-t
April 2021 FUNCTIONAL & TECHNICAL DESCRIPTION 2-7
120Vac, 60Hz, 0.9A or
230/240Vac, 50/60Hz, 0.5A
Epson LX-300+II printer (optional)
99-132Vac, 50/60Hz, 0.6A (maximum 1.4A depending on the
character type)
198-264Vac, 50/60Hz, 0.3A (maximum 1.4A depending on the
character type)
Epson TM-295II Slip Printer (optional)
Input: 100-240Vac, 50/60Hz, 1.2A; Output: +24Vdc, 0.8A
Epson TM-U220D Roll Printer (optional)
Input: 100-240Vac, 50/60Hz, 1.0A max; Output: 24Vdc, 1.5A
HP DeskJet 6000/8000 Series Inkjet (or equivalent) Printer (optional)
100-240Vac, 50/60Hz, 1.5A
Line Filter
Line filter is provided internally.
Use of a filtered line is recommended if excessive line noise is anticipated.
Ground Current
Less than .5mA
Power Connector and Cable
A grounded 3-prong plug cord for the instrument that is approved for use at the user's
site must be used.
Interconnection of devices must be made using the cables supplied with the
instrument.
