CAPINTEC, INC. CAPRAC
®
-t
April 2021 SYSTEM INITIALIZATION 5-11
Printer Control Emulation Mode IBM PPR
Font Print Mode Utility
Font DRAFT Mode HSD
Font Pitch 10 CPI
Font Proportional Spacing No
Font Style Normal
Font Size Single
Symbol Sets Character Set Set I
Symbol Sets Language Set American
Symbol Sets Zero Character Slashed
Symbol Sets Code Page USA
Rear Feed Line Spacing 6 LPI
Rear Feed Form Tear-Off Off
Read Feed Skip Over Perforation No
Rear Feed Page Length 11”
Bottom Feed Line Spacing 6 LPI
Bottom Feed Form Tear-Off Off
Bottom Feed Skip Over Perforation No
Bottom Feed Page Length 11”
Top Feed Line Spacing 6 LPI
Top Feed Bottom Margin Valid
Top Feed Page Length 11”
Top Feed Wait Time 1 sec
Top Feed Page Length Control by Actual Page Length
Set-Up Graphics Uni-directional
Set-Up Receive Buffer Size 64K
Set-Up Paper Out Override No
Set-Up Print Registration 0
|||||||||||||||||||||||||||||||||||||||||||||
SET
||||||
SHIFT+SET
|||||||||||||||||||
Set-Up Operator Panel Functions Full Operation
Set-Up Reset Inhibit Yes
Set-Up Print Suppress Effective No
Set-Up Auto LF No
Set-Up Auto CR No
Set-Up SI Select Pitch (10CPI) 17.1 CPI
Set-Up SI Select Pitch (12CPI) 12 CPI
Set-Up Time Out Print Valid
Set-Up Auto Select No
Set-Up Centering Position DEFAULT
Set-Up ESC SI Pitch 17.1 CPI
Parallel I/F I-Prime Buffer Print
Parallel I/F Pin 18 +5v
Parallel I/F Bi-Direction Enable
Serial I/F Parity None
Serial I/F Serial Data 7/8 Bits 8 bits
Serial I/F Protocol X-ON/X-OFF
Serial I/F Diagnostic Test No
Serial I/F Busy Line SSD-
Serial I/F Baud Rate 4800 BPS
Serial I/F DSR Signal Invalid
Serial I/F DTR Signal Ready on Power Up
Serial I/F Busy Time 200 ms
Figure 5-8 Listing of the Turbo OKIDATA 320 Printer Setup Data
<-----
----->
