Cisco Aironet 2.4 GHz 13-dBi Directional Antenna (AIR-ANT2413P2M-N)
Figure 2 Attaching Elevation Adjustable Bracket
4. Attach azimuth adjustable bracket to pipe routing band clamps as shown. Tighten the pipe clamps to a torque of 43-51
in-lbf (4.9-5.8 Nm).
1 Elevation adjustable bracket 4 1/4-in. spring lock washer
2 1/4-in. 20x3/4 carriage bolt 5 1/4-in. 20 hex nut
3 1/4-in. flat washer
334631
2345
1
5
43
2
