Cisco Aironet 2.4 GHz 13-dBi Directional Antenna (AIR-ANT2413P2M-N)

Figure 3 Attaching Azimuth Adjustable Bracket

5. Attach antenna assembly to azimuth bracket on pipe.

Azimuth adjustable bracket

Pipe clamps

334635
