Cisco Aironet 2.4-GHz/5-GHz 8-dBi Directional Antenna (AIR-ANT2588P3M-N)

Installing the Antenna

Figure 1 Attaching Antenna Mount Bracket

3. Attach elevation adjustable bracket as shown and loosely secure hardware.

1 Antenna 3 Antenna mount bracket

2 Stud nut

334672
