Cisco RF Cables and Accessories
Table 1 N(m) to N(m) RF cables
Antenna Cable Type Description RF Loss
AIR-CAB002L240-N N(m)-STR to N(m)-RA
LMR-240, 2 foot RF cable
Type: Indoor Interconnect.
Not DB, CMR or CMP
0.2dB @ 0.7 GHz
0.3dB @ 1.0 GHz
0.4dB @ 1.7 GHz
0.5dB @ 2.4 GHz
0.8dB @ 5.8 GHz
AIR-CAB005LL-N N(m)-STR to N(m)-RA
LMR-400, 5 foot RF cable
Type: outdoor DB (direct burial)
0.2dB @ 0.7 GHz
0.3dB @ 1.0 GHz
0.4dB @ 1.7 GHz
0.5dB @ 2.4 GHz
0.8dB @ 5.8 GHz
CAB-L400-5-N-N N(m)-STR to N(m)-RA
LMR-400, 5 foot RF cable
Type: outdoor DB (direct burial)
0.2dB @ 0.7 GHz
0.3dB @ 1.0 GHz
0.4dB @ 1.7 GHz
0.5dB @ 2.4 GHz
0.8dB @ 5.8 GHz
CAB-L400-5-N-NS N(m)-STR to N(m)-STR
LMR-400, 5 foot RF cable
Type: outdoor DB (direct burial)
0.2dB @ 0.7 GHz
0.3dB @ 1.0 GHz
0.4dB @ 1.7 GHz
0.5dB @ 2.4 GHz
0.8dB @ 5.8 GHz
AIR-CAB010LL-N N(m)-STR to N(m)-RA
LMR-400, 10 foot RF cable
Type: outdoor DB (direct burial)
0.4dB @ 0.7 GHz
0.5dB @ 1.0 GHz
0.7dB @ 1.7 GHz
0.9dB @ 2.4 GHz
1.5dB @ 5.8 GHz
CAB-L400-20-N-N N(m)-STR to N(m)-RA
LMR-400, 20 foot RF cable
Type: outdoor DB (direct burial)
0.8dB @ 0.7 GHz
1.0dB @ 1.0 GHz
1.3dB @ 1.7 GHz
1.6dB @ 2.4 GHz
2.5dB @ 5.8 GHz
AIR-CAB025HZ-N N(m)-STR to N(m)-STR
LMR-400, 25 foot RF cable
Type: outdoor DB (direct burial) with additional resistance to petrochemicals
and oils
1.0dB @ 0.7 GHz
1.2dB @ 1.0 GHz
1.6dB @ 1.7 GHz
2.0dB @ 2.4 GHz
3.1dB @ 5.8 GHz
CAB-L600-30-N-N N(m)-STR to N(m)-RA
LMR-600, 30 foot RF cable
Type: outdoor DB (direct burial)
0.8dB @ 0.7 GHz
0.9dB @ 1.0 GHz
1.3dB @ 1.7 GHz
1.6dB @ 2.4 GHz
2.6dB @ 5.8 GHz
