Cisco RF Cables and Accessories
Table 2 N(m) to QMA(m) RF cables
Table 3 N(m) to RPTNC(jack) RF cables
Table 4 N(m) to RPTNC(plug) RF cables
Table 5 RPTNC(plug)-STR to RPTNC(jack)-STR
Antenna Cable Type Description RF Loss
CAB-L240-10-Q-N N(m)-STR to QMA(m)-RA
LMR-240, 10 foot RF cable
Type: FR/CMR (Communication Cable Riser)
0.8dB @ 0.7 GHz
0.9dB @ 1.0 GHz
1.2dB @ 1.7 GHz
1.5dB @ 2.4 GHz
2.4dB @ 5.8 GHz
CAB-L240-15-Q-N N(m)-STR to QMA(m)-RA
LMR-240, 15 foot RF cable
Type: FR/CMR (Communication Cable Riser)
1.1dB @ 0.7 GHz
1.4dB @ 1.0 GHz
1.8dB @ 1.7 GHz
2.2dB @ 2.4 GHz
3.5dB @ 5.8 GHz
CAB-L240-20-Q-N N(m)-STR to QMA(m)-RA
LMR-240, 20 foot RF cable
Type: FR/CMR (Communication Cable Riser)
1.5dB @ 0.7 GHz
1.8dB @ 1.0 GHz
2.4dB @ 1.7 GHz
2.9dB @ 2.4 GHz
4.7dB @ 5.8 GHz
Antenna Cable Type Description RF Loss
CAB-L240-10-N-R N(m)-RA to RPTNC(jack)-STR
LMR-240, 10 foot RF cable
Type: outdoor DB (direct burial)
1.5dB @ 2.4 GHz
2.4dB @ 5.8 GHz
CAB-L400-20-N-R N(m)-RA to RPTNC(jack)-STR
LMR-400, 20 foot RF cable
Type: outdoor DB (direct burial)
1.6dB @ 2.4 GHz
2.5dB @ 5.8 GHz
Antenna Cable Type Description RF Loss
AIR-CAB005LL-R-N N(m)-RA to RPTNC(plug)-STR
LMR-240, 5 foot RF cable
Type: outdoor DB (direct burial)
0.5dB @ 2.4 GHz
0.8dB @ 5.8 GHz
Antenna Cable Type Description RF Loss
AIR-CAB005PL-R RPTNC (plug)-STR to RPTNC (jack)-STR
LMR-195, 5 foot RF cable
Type: Plenum
1.1dB @ 2.4 GHz
1.8dB @ 5.8 GHz
AIR-CAB005LL-R RPTNC (plug)-STR to RPTNC (jack)-STR
LMR-400, 5 foot RF cable
Type: outdoor DB (direct burial)
0.5dB @ 2.4 GHz
0.8dB @ 5.8 GHz
CAB-L400-10-R RPTNC (plug)-RA to RPTNC (jack)-STR
LMR-400, 10 foot RF cable
Type: outdoor DB (direct burial)
0.8dB @ 2.4 GHz
1.4dB @ 5.8 GHz
AIR-CAB020LL-R RPTNC (plug)-STR to RPTNC (jack)-STR
LMR-400, 20 foot RF cable
Type: outdoor DB (direct burial)
1.3dB @ 2.4 GHz
2.5dB @ 5.8 GHz
