Figure 2 shows a side view of the 4G-ANTM-OM-CM antenna.
Figure 2 Cisco 4G-ANTM-OM-CM Antenna (Side View)
1 Mounting screws and anchors (#6 x 1-1/4”)
for mounting on a hard ceiling
5 Mounting nut
2 Self-adhesive screw covers 6 Antenna cable
3 Flat washer (wide series) 7 TNC male connector
4 Curved spring washer 8 Thread (3/4”-16)
245636
1
2
3
4
5
8
6 7
